Kirloskar 1 HP Single Phase 14 Stage Water Filled Borewell Submersible Pump Set With Control Panel, LEHR 30 -1014
The Kirloskar 1 HP Single Phase 14 Stage Water Filled Borewell Submersible Pump Set With Control Panel, LEHR 30 -1014 is engineered for high performance in diverse water-lifting applications. Designed to operate efficiently within a wide voltage range of 220 V, this pump minimizes the risk of motor burnout during low voltage fluctuations. Its advanced water-filled motor ensures smoother, cooler, and long-lasting operation, while the sand fighter design adds durability by restricting sand entry—ideal for sandy borewells.
Built at a state-of-the-art facility, this pump boasts high energy efficiency with low power consumption, leading to significant cost savings. Precision-engineered with graded cast iron, stainless steel shaft, Noryl impellers, and 99.9% pure copper winding wires, it ensures durability and long life. Dynamically balanced rotating parts reduce vibration for consistent performance. Additionally, the CED (Cathodic Electro Deposition) coating offers superior corrosion resistance—5x better than conventional painting—ensuring the pump withstands harsh conditions for years.
Type of Product | Borewell Submersible Pump Set |
Product Sub Type | Water Filled Submersible Pump |
Series | LEHR 30 Series |
Borewell Size | 4 inch |
Phase | Single Phase |
Material | Motor Housing - Stainless Steel Motor Shaft - Stainless Steel Pump Bushes - NBR Impeller - Noryl Diffuser - Noryl NRV - Cast Iron Suction - Cast Iron |
Protection | IP68 |
Flow Rate | 0-60 LPM |
Power | 1 HP |
Voltage | 220 V |
Frequency | 50 Hz |
Model No | LEHR 30 -1014 |
Stage | 14 Stage |
Application | • Domestic and community water supply • Rural water supply • Gardening and small farm irrigation • Construction site |
Bore Size | 100 mm |
Outlet size | 32 mm |
Item Code | D11KH01010614536 |
Head Range | 102-30 m |
Power Rating | 0.75 kW |
Pump Shaft | Stainless Steel |
Country of Origin | India |
Package Contains | 1 Pump + 1 Control Panel |
Rated Current | 8.2 Amp |
Pump Housing Material | Stainless Steel |
Name of Manufacturer/Packer/Importer | Kirloskar Brothers Limited |
Insulation | B - Class |
